Back_propagation_algorithm.Back_propagation_algorithm.Back_propagation_algorithm
- 2. What is neural network? The term neural network was traditionally used to refer to a network or circuit of biological neurons. The modern usage of the term often refers to artificial neural networks, which are composed of artificial neurons or nodes.
- 3. In the artificial intelligence field, artificial neural networks have been applied successfully to speech recognition, image analysis in order to construct software agents or autonomous robots.
- 4. Neural networks resemble the human brain in the following two ways: A neural network acquires knowledge through learning A neural network's knowledge is stored within inter-neuron connection strengths known as synaptic weights.
- 5. How A Multi-Layer Neural Network Works? The inputs to the network correspond to the attributes measured for each training tuple Inputs are fed simultaneously into the units making up the input layer They are then weighted and fed simultaneously to a hidden layer The number of hidden layers is arbitrary, although usually only one The weighted outputs of the last hidden layer are input to units making up the output layer, which emits the network's prediction The network is feed-forward in that none of the weights cycles back to an input unit or to an output unit of a previous layer From a statistical point of view, networks perform nonlinear regression: Given enough hidden units and enough training samples, they can closely approximate any function
- 6. Back propagation algorithm Backpropagation: A neural network learning algorithm Started by psychologists and neurobiologists to develop and test computational analogues of neurons A neural network: A set of connected input/output units where each connection has a weight associated with it During the learning phase, the network learns by adjusting the weights so as to be able to predict the correct class label of the input tuples Also referred to as connectionist learning due to the connections between units
- 7. Contd.. Iteratively process a set of training tuples & compare the network's prediction with the actual known target value For each training tuple, the weights are modified to minimize the mean squared error between the network's prediction and the actual target value Modifications are made in the “backwards” direction: from the output layer, through each hidden layer down to the first hidden layer, hence “backpropagation” Steps Initialize weights (to small random #s) and biases in the network Propagate the inputs forward (by applying activation function) Backpropagate the error (by updating weights and biases) Terminating condition (when error is very small, etc.)
- 8. Contd.. Efficiency of backpropagation: Each epoch (one interation through the training set) takes O(|D| * w), with |D| tuples and w weights, but # of epochs can be exponential to n, the number of inputs, in the worst case Rule extraction from networks: network pruning Simplify the network structure by removing weighted links that have the least effect on the trained network Then perform link, unit, or activation value clustering The set of input and activation values are studied to derive rules describing the relationship between the input and hidden unit layers Sensitivity analysis: assess the impact that a given input variable has on a network output. The knowledge gained from this analysis can be represented in rules
- 9. Two phases: propagation and weight update. Phase 1: Propagation Each propagation involves the following steps: Forward propagation of a training pattern's input through the neural network in order to generate the propagation's output activations. Back propagation of the propagation's output activations through the neural network using the training pattern's target in order to generate the deltas of all output and hidden neurons.
- 10. Contd.. Phase 2: Weight update For each weight-synapse: Multiply its output delta and input activation to get the gradient of the weight. Bring the weight in the opposite direction of the gradient by subtracting a ratio of it from the weight. This ratio influences the speed and quality of learning; it is called the learning rate. The sign of the gradient of a weight indicates where the error is increasing, this is why the weight must be updated in the opposite direction. Repeat the phase 1 and 2 until the performance of the network is good enough.
- 11. Actual algorithm for a 3-layer network (only one hidden layer): Initialize the weights in the network (often randomly) Do For each example e in the training set O = neural-net-output (network, e) ; forward pass T = teacher output for e Calculate error (T - O) at the output units Compute delta_wh for all weights from hidden layer to output layer ; backward pass Compute delta_wi for all weights from input layer to hidden layer ; backward pass continued Update the weights in the network Until all examples classified correctly or stopping criterion satisfied Return the network
- 12. Weakness Long training time Require a number of parameters typically best determined empirically, e.g., the network topology or ``structure." Poor interpretability: Difficult to interpret the symbolic meaning behind the learned weights and of ``hidden units" in the network Strength High tolerance to noisy data Ability to classify untrained patterns Well-suited for continuous-valued inputs and outputs Successful on a wide array of real-world data Algorithms are inherently parallel Techniques have recently been developed for the extraction of rules from trained neural networks
- 13. Thank You!!!
